XACA471

Description

‌Parameters & Specifications‌:
–‌Product Category‌: Pushbutton Switches1.
–‌Manufacturer‌: Schneider Electric21.
–‌Installation Style‌: Panel Mount21.
–‌Number of Pushbuttons‌: Typically 4 (Double insulated type)1.
–‌Voltage Ratings‌:

• AC: 600 VAC (A600 AC-15, Ue = 600 V, Ie = 1.2 A)1.
• DC: 600 VDC (Q600 DC-13, Ue = 600 V, Ie = 0.1 A)1.
  –‌Current Ratings‌:
• AC: 3 A (A600 AC-15, Ue = 240 V)2.
• DC: Varies depending on the specific application
•
  ‌Dimensions & Weight‌:
  –‌Dimensions‌: Specific dimensions are not provided, but it is designed for panel mounting21.
  –‌Weight‌: Weight information is not directly provided; however, it is expected to be lightweight for ease of installation and handling.
  ‌Series‌:
  –‌Series‌: XACA Series3.
  ‌Features‌:
  –‌IP65 Rated‌: Provides protection against dust and water jets, suitable for harsh industrial environments2.
  –‌Double Insulated‌: Ensures electrical safety1.
  –‌Polypropylene Enclosure‌: Provides durability and resistance to chemicals2.
  –‌Screw Clamp Terminals‌: Facilitates easy and secure wiring1.
  –‌Multiple Pushbutton Configurations‌: Supports various control functions, such as raise, lower, left, right, and emergency stop1.
  ‌Functions‌:
  –‌Control Station‌: Acts as a control interface for industrial machinery, allowing operators to control various functions through pushbuttons1.
  –‌Machine Operation‌: Enables operators to start, stop, and adjust the speed and direction of machinery, improving process efficiency and safety
