WOODWARD SPC 8200-226

Description

WOODWARD SPC 8200-226 is an advanced servo position controller designed for precise positioning and control in industrial automation systems. Here is a breakdown of its parameters, specifications, dimensions, weight, series, features, and applications in English:

Parameters and Specifications:

• Input Voltage: The controller supports multiple input voltages, typically 24VDC for servo control applications¹² and 12VDC for power management applications³.
• Output: Depending on the application, the output can range from 0 to 20mA for servo control¹ or provide a fixed output voltage of 10VDC for power management³.
• Operating Temperature Range: It operates within a wide temperature range of -40°C to 85°C, ensuring reliable performance in extreme conditions¹³.

Dimensions and Weight:

• Dimensions: The SPC 8200-226 measures approximately 10cm x 10cm x 2cm for servo control applications¹ and 2.0″ x 2.0″ x 0.5″ (5.08cm x 5.08cm x 1.27cm) for power management applications³.
• Weight: The weight is approximately 0.1 lbs (0.045 kg) for the power management module³, while the servo controller’s weight is not specifically mentioned.

Series:

• The 8200-226 belongs to the Woodward SPC series of servo controllers or power management modules.

Features:

• Precision Control: The SPC 8200-226 offers precise positioning and control through servo motor drive, enabling high-degree transmission system positioning¹.
• Wide Input Voltage Range: Its ability to accept multiple input voltages enhances its compatibility with different systems¹³.
• Robustness: The controller is designed for reliable operation in harsh industrial environments¹³.
• Safety Features: Power management modules include safety features like overvoltage protection, overcurrent protection, and short-circuit protection³.

Applications:

• The Woodward SPC 8200-226 is suitable for a wide range of industrial automation applications, including high-precision positioning systems¹.
• It can be used in various industries such as electronics, automation, aerospace, shipping, military, and more³.
