Description
WOODWARD 9907-164 is a digital microprocessor-based controller specifically designed for turbines equipped with single-range or split-range actuators. It belongs to the 505 series of controllers, a product line known for its precision and reliability in industrial control applications. Here are the key parameters, specifications, dimensions, weight, series, features, and functions of the WOODWARD 9907-164 in English:
Parameters and Specifications:
Model Number: 9907-164.
Brand: WOODWARD.
Voltage: Typically operates at +24 Vdc 1 A.
Input/Output: Includes a series of discrete and analog inputs, such as 16 contact inputs (4 dedicated, 12 programmable) and 6 programmable current inputs (4-20 mA).
Dimensions and Weight:
Dimensions: Exact dimensions may vary, but typical controllers in this class are designed for compact installation within industrial control cabinets.
Weight: Approximately 9.11 pounds (1.24kg).
Series:
505 Series: The 9907-164 controller is part of the 505 series, a line of microprocessor-based controllers specifically designed for turbines, turbo generators, and turbo-expander modules.
Features:
Accurate and Reliable Control: The controller provides precise and reliable control of turbines, ensuring stable and efficient operation.
User-Friendly Interface: Features a 30-key multifunction keyboard and a two-line text display with 24 characters per line, allowing for easy configuration and monitoring by field operators.
Flexible Configuration: Can be configured on-site by field operators using the integrated operator control panel.
Standard Functions: Includes features like critical speed avoidance, valve limiters, automatic start sequences, and shutdown priority indicators for enhanced safety and efficiency.
Functions/Applications:
Turbine Control: The 9907-164 is primarily used to control turbines, specifically their single-extraction and/or inlet steam applications.
Industrial Automation: It is suitable for use in industrial automation systems, where precise and reliable control of turbines is critical for efficient operation.
Turbine-Driven Systems: Can be used in systems where turbines drive generators, pumps, or other equipment, providing precise control and monitoring capabilities.
Please note that the specific parameters, specifications, dimensions, and weight may vary slightly depending on the manufacturer’s updates or customizations. It is always advisable to refer to the official product documentation or contact the manufacturer for the most accurate and up-to-date information. Additionally, when installing or operating industrial equipment, it is crucial to follow all safety procedures and regulations to ensure safe and reliable operation.
