Description
Woodward 5501 – 470
The Woodward 5501 – 470 is a high – performance CPU module designed for industrial control systems. It is a key component of Woodward’s MicroNet Simplex LV controller series, playing a central role in Woodward control systems.
Product Description
The Woodward 5501 – 470 offers excellent data processing capabilities, enabling it to quickly and accurately process various control data, thus ensuring the real – time response and efficient operation of the system1. It uses advanced microprocessors and algorithms to achieve high – speed, accurate data processing and control1. At the same time, it supports a variety of communication protocols and control methods, which is convenient for integration and application with various control devices and systems1. As part of the Woodward control system, the 5501 – 470 module is perfectly compatible with other Woodward components, enabling seamless integration and efficient collaboration1. In addition, its modular design makes installation and maintenance simple and fast, reducing maintenance costs and time1.
Product Parameters
- Input voltage: 24 V DC8
- Output voltage: 24 V DC8
- Input channels: 168
- Output channels: 168
- Communication interface: PROFIBUS DP, 2 serial ports, 1 Ethernet port813
- Processor: 32 – bit RISC CPU, 100 MHz13
- Memory: 256 KB RAM, 1 MB flash storage13
- Operating temperature: – 20 °C to 60 °C813
- Protection rating: IP65 for dust and water resistance13
- Dimensions: 13.4 cm (w) x 8.5 cm (d) x 3.5 cm (h)13
- Weight: 0.5 kg13
Advantages and Characteristics
The 5501 – 470 is known for its outstanding performance and stability1. It is built with high – quality materials and advanced technology, which can ensure stable and reliable operation in a variety of complex and harsh industrial environments1. The module has a compact and efficient design that can be seamlessly integrated into the existing industrial control system. Its modular architecture is convenient for installation and maintenance, which helps to reduce downtime and increase productivity. In addition, the 5501 – 470 has strong programmability, and users can write customized control logic and programs according to specific application requirements to achieve flexible automatic control solutions1.
Application Areas and Application Cases
The Woodward 5501 – 470 is widely used in industrial automation production lines, aerospace control systems, energy equipment monitoring and other fields, providing stable and reliable control solutions for various industrial applications1. For example, in a power generation plant, the 5501 – 470 can be used to monitor and control the operation of turbines and generators, ensuring the stable output of electricity. It can collect various data in real time, such as temperature, pressure, and rotation speed, and perform corresponding control and adjustment according to the set parameters, thereby improving the efficiency and reliability of power generation equipment.
Comparison with Competing Products
Compared with similar products, the Woodward 5501 – 470 has the advantages of higher processing capacity and stronger stability. It can process a large amount of control data in real time, and its stable performance can reduce the risk of system failure. In addition, its modular design and rich communication interfaces make it more convenient to integrate with other devices and systems, and have better compatibility and expandability.
Selection Recommendations
When selecting the Woodward 5501 – 470, users should first consider the compatibility with the existing control system to ensure that it can be seamlessly integrated. Secondly, the installation environment should be taken into account. The module is suitable for a wide range of operating temperatures, but it should be avoided to be installed in an environment with high humidity, strong vibration or severe dust. In terms of budget, although the 5501 – 470 is a high – performance product, users can choose according to their actual needs and economic strength.
Precautions
During the use and installation of the Woodward 5501 – 470, it is necessary to follow the relevant safety regulations. When installing, make sure to cut off the power supply to avoid electric shock. During operation, do not touch the module with wet hands to prevent short – circuit damage. In addition, regular maintenance and inspection are required to check whether the connection is loose and whether there is dust accumulation inside the module. It is recommended to replace the module according to the specified service life to ensure the stable operation of the system.
Shanxi Runsheng Import and Export Co., Ltd. is your reliable partner. We provide the sales and technical support of Woodward 5501 – 470 and other automation spare parts. Please visit our website www.sxrsrobot.com or contact us, and we will serve you wholeheartedly.
