Woodward 2301E 8273-1011

Description

Parameter Specifications

1. Power Supply: The Woodward 2301E 8273 – 1011 typically operates on a 115V or 230V AC power supply, with a frequency range of 50/60Hz. The power consumption is around 20 – 30W, depending on the operating conditions.
2. Control Range: It is designed to control the speed of engines or turbines. The speed control range can be adjusted from a minimum of around 500 RPM to a maximum of 5000 RPM, which can be customized according to the specific application requirements.
3. Input Signals: It can accept various input signals for control purposes. These include speed feedback signals from magnetic pick – up sensors or tachometers, as well as external control signals such as remote set – point signals for speed adjustment.
4. Output Signals: The unit provides output signals to control the fuel valve or governor actuator. The output is a proportional control signal that can be adjusted to regulate the fuel flow or the position of the governor, thereby controlling the speed of the engine or turbine.

Applications

1. Power Generation: In small to medium – sized power plants, the Woodward 2301E 8273 – 1011 is used to control the speed of diesel or gas engines driving generators. It ensures stable power output by maintaining a constant engine speed, even under varying load conditions.
2. Marine Applications: On ships, it can be used to control the speed of main engines or auxiliary engines. This helps in efficient propulsion and operation of onboard electrical systems.
3. Industrial Machinery: In industrial settings, it can be used to control the speed of turbines or engines powering compressors, pumps, or other heavy – duty machinery.

Weight and Dimensions

1. Weight: Approximately 5 kg, which is relatively manageable for installation and maintenance.
2. Dimensions: It has dimensions of about 300mm (length) x 200mm (width) x 150mm (height). The compact design allows it to be easily installed in control cabinets or engine compartments.

Features

1. Precise Speed Control: It offers precise speed control capabilities, ensuring that the engine or turbine operates at a constant speed within a narrow tolerance range. This is crucial for applications where stable power output or consistent machinery operation is required.
2. Adjustable Parameters: The control parameters such as speed set – point, gain, and droop can be easily adjusted through the front – panel controls or a programming interface. This allows for customization based on the specific requirements of the application.
3. Self – Diagnostic Function: It is equipped with a self – diagnostic function that can detect faults in the control unit, input signals, or output actuators. This helps in quick troubleshooting and reduces downtime.

Stability and Reliability

1. Robust Construction: Built with high – quality components and a durable enclosure, it can withstand harsh operating environments, including vibrations, temperature variations, and electrical interference.
2. Long – term Testing: Woodward conducts extensive long – term testing on the 2301E 8273 – 1011 to ensure its stability and reliability over a long service life.
3. Redundancy Options: Some configurations may support redundancy in power supply or control functions, providing an additional layer of reliability in critical applications.
