Description
Parameters and specifications:
Operating voltage range: 12-36V.
Power supply voltage range: 8-40V.
Maximum power consumption: 40W.
Static current consumption: 16.9MA/24V; 17.5MA/36V (measured with a 10K potentiometer at the end of the reference output voltage).
Reference power supply short circuit protection current threshold: 50MA.
External output current: 5V<10MA.-5V<2MA.
Power-on delay time: 0.5 seconds (the current output is available only after the power-on delay time).
Communication rate: Maximum 57600 bps, which can be set to 9600 bps and 57600 bps through the switch, or other transmission Settings.
Features:
Multiplexer: Used to connect the I/O bus, DPR, and redundant CU.
Battery backup: Battery backup for the sRAM is provided through the central module with monitoring and the battery on the bus board.
Two RS 485 interfaces: with current isolation.
Diagnostic displays and LED indicators: Used to display information outside the system, I/O levels, and user programs.
Dual port RAM: For quick access to the second central module (not used in the H41q MS system).
Hardware clock: Supports battery.
Power monitoring and battery monitoring: testable (5 V system voltage).
Proportional amplifier: Electronic control unit suitable for open-loop proportional valves, the output current is proportional to the reference signal, independent of temperature changes and load impedance.
Functions:
The VT5035-17B is a versatile amplifier module commonly used in industrial automation systems, especially in applications that require precise control of proportional valves in hydraulic or pneumatic systems. It can receive the signal from the control system and convert it into the current signal suitable for the control proportional valve, so as to achieve the precise control of the system flow, pressure or other parameters.
