Description
argument
Processor: Pentium® III processor up to 1.26 GHz with 512 Kbyte (512 Kbyte at 1.26 GHz) advanced transfer cache
Memory:
The maximum memory capacity is 512 Mbyte, using a single 144-pin SDRAM SODIMM
The graphics adapter is complemented by a 4 Mbyte external synchronous DRAM cache
Graphics:
The built-in 815E chipset AGP graphics adapter supports high-resolution graphics and multimedia quality video
The graphics adapter supports screen resolutions of up to 1,600 x 1,200 x 256 colors (single view mode)
specification
Chipset: Intel 815E chipset with a front end bus rate of 133 MHz
Interface:
Supports the PMC extension interface
Two RS232 serial ports
VME P1: Standard VME connector
VME P2: VME64 connector
System bus: 133 MHz system bus via Intel® 815E chipset
Network:
Dual Ethernet controller, support 10BaseT and 100BaseTX, via two RJ45 connectors
Supports remote LAN booting, utilizing BootWare® from Lanworks Technologies
Size and weight
Dimensions: 170mm x 105mm x 32mm
Weight: About 120g
trait
High-performance processor: Pentium III processor with 32-bit addressing and 64-bit data bus, superscalar architecture allows three instructions per clock cycle
Advanced graphics support: Built-in AGP SVGA controller, with 4 Mbyte display cache, support for high-resolution graphics and multimedia quality video
Dual-port DRAM: DRAM is dual-port connected to VME, providing high bandwidth and high performance
Flexible boot options: Support for remote LAN booting with BootWare® for remote boot over NetWare, TCP/IP or RPL network protocols
Multi-os support: ows 2000, VxWorks®, Solaris™, QNX®, LynxOS®, and Linux® systems are supported
