Description
argument
Interface: VMEbus.
Number of channels: 16.
Analog input/output resolution: all 16 bits.
Digital I/O: 32 lines.
Operating temperature range: Depending on the source, it may be -40 ° C to +85 ° C or -25 ° C to 70 ° C.
Network transfer rate: 43 Mbyte/s (4-byte packet) to 170 Mbyte/s (64-byte packet).
Serial rate: 2.12 Gbaud.
specification
Input voltage: 5VDC (but another message states that the input voltage range is 10-30VDC and the output voltage is 24VDC).
Power consumption: 10W (but another message states that the output power is 360W, which may refer to the power of the entire system or module, not the power consumption of the card alone).
Size:
6U VMEbus form factor (a standard size).
Another message gives a specific size of 96mm x 48mm x 16mm, but this could be the size of one of the components on the card.
There is also a message indicating that the external dimensions are 36.3cm x 19.6cm x 20.6cm, which may refer to the dimensions of the entire module or case containing the card.
Weight:
200g.
Another message indicated that the weight was about 1.2kg
trait
Ultrafast Shared Memory: An ultrafast shared memory network solution based on halo that allows a distributed network to share real-time data at a determined rate.
Dynamic packet size: Packet sizes from 4 to 64 bytes are supported.
High node count: Supports a maximum of 256 nodes.
Long distance connection: The connection with multi-mode fiber can be up to 300 meters, and the connection with single-mode fiber can be up to 10 kilometers.
Fault tolerance: Support for patented fault tolerance operations improves reliability relative to other process controllers.
High-precision timing and control: Possible support for multi-channel control, high-precision timing, pulse frequency and width adjustment, multiple trigger modes, and more.
