Description
argument
Analog input channels: 64 differential or single-ended inputs.
A/D converter resolution: 16 bits.
Scanning rate:
High performance options: 381 Hz to 100 kHz.
Standard performance options: 381 Hz to 50 kHz.
Programmable channel gain: x1 or x10.
A/D converter range: ± 2.5V, ± 5V, ± 10V, 0 to + 5V, 0 to + 10V.
specification
Data buffer: 16 to 1,024 word dual-port data buffer.
Data space: Supports operations with short I/O (A16), standard (A24), or extended (A32) data space.
Operation mode: Supports automatic scanning, data burst, and external synchronization.
trait
High resolution: 16-bit A/D converter provides high precision measurement.
Multi-channel input: Supports 64 differential or single-ended analog inputs for applications requiring high-density analog inputs.
Flexible configuration: Programmable channel gain, scan rate and data buffer size to meet different application requirements.
Powerful data processing capabilities: Dual port data buffers support efficient data transmission and processing.
Extensive interface support: Directly connected to the VMIC’s signal conditioning board to digitize the output of thermocouples, RTDS and strain gauges.
