Description
argument
Digital resolution: 16 bits
Number of analog input channels: 64 differential or single-ended
Scanning rate:
High performance options: 381 Hz to 100 kHz
Standard performance options: 381 Hz to 50 kHz
Gain: Programmable gain, x1 or x10
A/D converter range: ± 2.5V, ± 5V, ± 10V, 0 to + 5V, 0 to + 10V
Dual port data buffer: 16 to 1,024 words
specification
Operation mode: Supports automatic scanning, data burst, and external synchronization
Data space: Can operate in short I/O (A16), standard (A24), or extended (A32) data space
Programmable channel block size and buffer size: Channel blocks can be adjusted to 1, 8, 16, 32, or 64 channels, and data buffer sizes can be selected in binary increments from 16 data words to 1,024 data words
Low-pass input filter: Optional
Size and weight
Size: 121212
trait
High resolution: 16-bit A/D conversion for high precision measurement
Multi-channel automatic scanning: Supports automatic scanning of 64 differential or single-ended analog inputs
Programmable gain: The gain for each channel can be programmed individually or set by software to a fixed gain common to all channels
Dual port data memory: facilitates real-time data access and processing
Onboard timers and bus interrupters: Simplify data monitoring and management
Supports multiple operation modes, including automatic scanning, data burst, and external synchronization
