Description
argument
Processor: Intel® Pentium® M, available at 1.1 GHz, 1.4 GHz, or 1.8 GHz
Level 2 cache: up to 2 Mbyte (1.4 GHz and 1.8 GHz options) and 1 Mbyte (1.1 GHz options)
Memory: Up to 1.5 Gbyte DDR SDRAM
Flash: Up to 2 Gbyte can start CompactFlash
System bus: 400 MHz
specification
Interface type: VME bus interface, used to communicate with other modules or systems
Signal type: Support digital and analog signal processing
Power requirements: Usually require a specific range of DC voltage power supply, such as input voltage range 85~264VAC, output voltage 24VDC
Ethernet ports: 10/100 BaseTX Ethernet port front, 10/100/1000 Base Tx Ethernet port front (non-VITA 31.1 option), 2 Gigabit Ethernet ports (VITA 31.1 optional)
Serial ports: 4 16550 compatible serial ports
USB ports: Four USB 2.0 ports
Graphics support: SVGA and DVI-I graphics support with Intel 855GME
Size and weight
Dimensions: 90 x 110 x 60 mm (or 10 x 7.6 x 1.2 inches)
Weight: Approx. 1.2 kg (or 21.3lb)
trait
High performance: Operating frequencies up to 1.8 GHz for I/O intensive applications
High bandwidth: Provides high bandwidth and processing capabilities
Flexibility: Support a variety of signal types and communication protocols to adapt to different application requirements
Easy configuration and maintenance: Provides user-friendly interfaces and tools to facilitate configuration, programming, and maintenance operations
High reliability and stability: After rigorous testing and verification, it can operate stably in harsh industrial environments for a long time
