Description
argument
Digital input channels: 16, can be configured separately
Input type: contact closure, voltage signal (0-30VDC) or current signal (0-24mA, filling or pulling current)
Input filter: programmable from 0 to 1 second
Enter the buffeting time: programmable from 0 to 500 ms
Input voltage isolation: 1500Vrms between field side and logical side
Input current isolation: 3000Vrms between field side and logical side
Operating temperature: -40°C to +70°C
Power consumption: up to 4 watts (some say 10W, but may vary by version or configuration)
Shock and vibration: tested to IEC 60068-2 standard
specification
Number of channels: 16 digital input channels
Compatibility: Triconex Trident safety instrumentation System
Compliance: ANSI/ISA-82.02.01-2004, IEC 61508 (SIL 3) certification
Size and weight
Size: The exact size may vary by product version, but the size of general industrial automation equipment is relatively compact. Some say it is 153mm long, 220mm high and 60mm wide, while others say it is 170mm long, 105mm wide and 32mm high.
Weight: Some say 1.23kg, some say about 120g, and some say 1.36kg.
trait
High reliability: Designed for safety-critical applications, such as the oil and gas industry, ensuring reliable monitoring of digital signals.
Rugged: able to withstand extreme temperatures, shock and vibration, suitable for harsh environments.
Flexible configuration: 16 channels can be configured separately, allowing users to set parameters such as input type, filter, and dejitter time.
Easy to install and configure: hot-swappable and can be replaced without interrupting Triconex system operation. This can be configured using Triconex’s TriStation 1131 software.
