Description
Parameters and Specifications:
Voltage: The TK-PRS021 operates on a 24V DC power supply
Current: The current range of the module is between 100-400A
Communication: It supports various communication methods, including RS232, RS422, RS485 serial communication, and Ethernet communication (wired and wireless)
Dimensions and Weight:
Dimensions: The exact dimensions of the TK-PRS021 are not provided in the recent search results, but it is mentioned as TK-PRS021mm3. It’s advisable to consult the manufacturer’s official documentation for precise measurements.
Weight: The weight of the module is approximately 2KG
Features:
PWM Pulse Formation: The TK-PRS021 utilizes the SG3525A as the primary technology for PWM (Pulse Width Modulation) pulse formation. It can output pulse frequencies ranging from 20KHZ to 60KHZ, with pulse intervals of 180 degrees and adjustable dead time
IGBT Drive: This control board is suitable for IGBT full-bridge inverter series resonant induction heating device frequency modulation and power adjustment. It has a power range of 10KW to 120KW and features a full-bridge inverter IGBT drive circuit, allowing direct assembly into IGBT high-frequency induction heating equipment
