Description
Series:
- Honeywell Process Control Modules Series
Parameters & Specifications:
*PWM Pulse Formation: Utilizes SG3525A for PWM (Pulse Width Modulation) pulse formation, capable of outputting pulse frequencies ranging from 20KHZ to 60KHZ12.
*IGBT Drive: Suitable for IGBT full-bridge inverter series resonant induction heating devices, allowing for frequency and power modulation with a power range of 10KW to 120KW12.
*Protection Features: Equipped with overcurrent, overvoltage, and water shortage status indications, along with switch-type and linear Hall protection interfaces12.
Dimensions & Weight:
*Dimensions: The dimensions vary slightly between sources, with one source mentioning 12.6cm x 12.7cm x 17.8cm3, and another specifying 132mm x 105mm x 52mm
*Weight: Approximately 2KG23.
Features:
*Multi-Functionality: Combines PWM pulse formation, IGBT drive, and multiple protection features in a single module12.
*Convenient Power Requirements: Operates on three-way AC dual 18V/1A and four 22V/0.5A power supplies12.
*Communication Capability: Potentially supports multiple communication methods, including RS232, RS422, RS485 serial communication, and Ethernet (wired and wireless)2.
Functions:
*Process Monitoring & Control: Monitors and controls various parameters in industrial production processes2.
*IGBT Drive Control: Directly assembles into IGBT high-frequency induction heating devices, providing precise control over frequency and power modulation
