T8480C

Description

Parameter Specifications

Power Supply: The T8480C usually operates on a 110 – 240V AC power supply with a frequency of 50/60Hz. This wide – range input allows it to be used in different regions without the need for additional power converters. The power consumption is around 30 – 50W, depending on the operating mode.
Display: It features a large – size display, typically a 15 – inch LCD screen with a resolution of 1024×768 pixels. This high – resolution display provides clear and sharp visuals for easy viewing of information.
Processor: Equipped with a mid – range processor, such as an Intel Celeron or similar, which offers sufficient processing power for running common industrial applications.
Memory: It has 2GB of RAM for smooth multitasking and 32GB of solid – state drive (SSD) storage for storing operating systems, applications, and user data.
Communication Interfaces: Multiple communication interfaces are available, including Ethernet (10/100Mbps), USB ports (USB 2.0 and USB 3.0), and serial ports (RS – 232/RS – 485) for connecting to other devices and systems.

Applications

Industrial Automation: In manufacturing plants, it can be used as a human – machine interface (HMI) for operators to monitor and control production processes. Operators can view real – time data from sensors, adjust parameters, and receive alarms.
Building Automation: In commercial buildings, it can be used to manage building systems such as HVAC, lighting, and security. It provides a centralized control and monitoring platform for building operators.
Medical Equipment: In some medical devices, it can serve as a display and control terminal, allowing medical staff to operate the equipment and view patient data.

Weight and Dimensions

Weight: Approximately 3 – 4 kg, which is relatively light considering its display size and functionality.
Dimensions: It has dimensions of about 380mm (length) x 300mm (width) x 50mm (height), making it suitable for installation on control panels or desks.
Features
User – Friendly Interface: The large touchscreen display provides an intuitive and easy – to – use interface. Operators can interact with the system using simple touch gestures, reducing the learning curve.
Customizable Software: It supports customizable software development, allowing users to create their own interfaces and applications according to specific requirements.
Remote Access: It supports remote access via Ethernet, enabling operators to monitor and control the device from a remote location using a computer or mobile device.

Stability and Reliability

Robust Design: Built with a sturdy enclosure and high – quality components, it can withstand normal industrial vibrations, shocks, and dust.
Power Protection: It is equipped with power protection features, such as over – voltage and under – voltage protection, to ensure stable operation even in the case of power fluctuations.
Long – term Testing: Through extensive long – term testing and quality control, it has been proven to have a high level of stability and reliability over a long service life.

Practical Case

In a food processing factory, the T8480C is used as an HMI for a packaging production line. Operators use the touchscreen to monitor the speed, temperature, and filling level of the packaging machines. One day, a sensor detected an abnormal temperature increase in one of the machines. The T8480C immediately displayed an alarm on the screen and sent a notification to the maintenance team via remote access. The maintenance team was able to quickly identify and fix the problem, preventing potential product quality issues and minimizing production downtime. Thanks to the stability and user – friendly features of the T8480C, the packaging production line continued to operate efficiently.
