SNAT603CNT

Description

Parameters and Specifications:

Model Number: SNAT603CNT
Brand: ABB
Input Type: Typically accepts a 4-20mA input signal.
Output Type: Provides an output signal of 0-10V.
Voltage: Operates on a 24V DC power supply.
Power: Consumes 20W of power.
Efficiency: Features a high-efficiency converter, achieving up to 90% efficiency.

Dimensions and Weight:

Dimensions: The module’s dimensions are typically 50mm x 100mm x 120mm. However, some sources indicate dimensions of 20013050mm or 365874mm. It’s advisable to consult the official ABB documentation for precise dimensions.
Weight: The weight of the module can vary depending on its specific construction and materials used. Some sources indicate a weight of approximately 1.85kg, but for a precise weight measurement, it’s best to refer to the manufacturer’s specifications.

Features:

Efficient Conversion: The module’s high-efficiency converter ensures minimal power loss during signal conversion.
Robustness: Designed for industrial environments, it can withstand a wide range of operating conditions.
Compatibility: It’s compatible with various ABB control systems and can be easily integrated into existing automation solutions.

Role & Function:

Signal Conversion: The SNAT603CNT module converts incoming analog signals (in this case, 4-20mA) to a voltage output (0-10V), making it suitable for use in systems that require this type of signal conditioning.
Process Control: By converting and conditioning input signals, the module plays a crucial role in process control, enabling precise monitoring and regulation of industrial processes.
