SM23165DT-DE

¥3,602.00

Weight and Dimensions



  1. Weight: Approximately 0.5 kg, which is relatively light and easy to handle during installation and maintenance.
  2. Dimensions: It has a compact design, with dimensions of about 120mm (length) x 100mm (width) x 40mm (height). This small size allows it to be easily installed in control boxes or other limited – space areas.

Features



  1. Dual Communication Options: The combination of Ethernet and RS – 485 communication interfaces provides flexibility in system integration. It can communicate with modern Ethernet – based devices as well as legacy serial – based equipment.
  2. Easy Configuration: Configuration is straightforward. Users can set up input/output functions, communication parameters, and other settings through software or a user – friendly interface, reducing the complexity of installation and operation.
  3. Scalability: It has a modular design, which means additional units can be easily added to expand the input/output capacity as the system requirements grow.
Category: Tag:

Description

Parameter Specifications



  1. Power Supply: The SM23165DT – DE operates on a 24V DC power supply. Its power consumption is approximately 8 – 12W, which is energy – efficient for long – term continuous use in industrial environments.
  2. Input/Output Channels: It features 16 digital input channels that can receive signals from a variety of sensors. These sensors can include proximity sensors, limit switches, and photoelectric sensors. There are also 16 digital output channels for controlling actuators such as solenoid valves, relays, and indicator lights.
  3. Communication Interface: It comes with an Ethernet communication interface, supporting a data transfer rate of up to 100Mbps. It adheres to the Modbus TCP protocol, enabling seamless data exchange with other devices in an industrial network. Additionally, it has an RS – 485 port for serial communication, which can be used for legacy device connections or for extended network setups.
  4. Operating Temperature Range: Designed to function within a temperature range of – 10°C to 55°C. This wide – range operation allows it to be used in different industrial settings, including those with some temperature fluctuations.

Applications



  1. Industrial Automation: In manufacturing plants, it can be used to control and monitor production lines. For example, it can manage the movement of conveyor belts based on the signals from sensors detecting the presence of products. It can also control the operation of small – scale assembly machines, ensuring efficient and accurate production processes.
  2. Building Automation: In commercial buildings, it can be used for basic control tasks such as controlling the lighting system based on occupancy sensors or monitoring the status of door locks. It can also be integrated into the HVAC system to regulate temperature and ventilation.
  3. Material Handling: In warehouses or logistics centers, it can control the movement of automated guided vehicles (AGVs) and manage the operation of conveyor systems for efficient material handling.

Weight and Dimensions



  1. Weight: Approximately 0.5 kg, which is relatively light and easy to handle during installation and maintenance.
  2. Dimensions: It has a compact design, with dimensions of about 120mm (length) x 100mm (width) x 40mm (height). This small size allows it to be easily installed in control boxes or other limited – space areas.

Features



  1. Dual Communication Options: The combination of Ethernet and RS – 485 communication interfaces provides flexibility in system integration. It can communicate with modern Ethernet – based devices as well as legacy serial – based equipment.
  2. Easy Configuration: Configuration is straightforward. Users can set up input/output functions, communication parameters, and other settings through software or a user – friendly interface, reducing the complexity of installation and operation.
  3. Scalability: It has a modular design, which means additional units can be easily added to expand the input/output capacity as the system requirements grow.

Stability and Reliability



  1. Robust Construction: Built with high – quality components and a durable enclosure, it can withstand normal industrial vibrations, minor shocks, and dust.
  2. Electrical Isolation: It provides electrical isolation between input/output channels and the power supply, protecting the device from electrical interference and ensuring stable signal transmission.
  3. Long – term Testing: Through extensive long – term testing, it has been proven to have a reliable performance over time, with a low failure rate.

Practical Case



In a small – scale electronics manufacturing plant, the SM23165DT – DE is used to control a pick – and – place machine. The digital input channels are connected to sensors that detect the position of electronic components on a tray. When a component is detected, the SM23165DT – DE sends a signal through the digital output channels to the pick – and – place mechanism to pick up the component and place it on the circuit board. One day, there was a brief power outage in the plant. Thanks to the electrical isolation feature and stable design of the SM23165DT – DE, the device retained its configuration and was able to resume normal operation immediately after the power was restored. The reliable performance of the SM23165DT – DE ensured the continuous and efficient operation of the pick – and – place process, improving the overall productivity of the manufacturing plant.
