Description
Parameters and Specifications:
Voltage: Rated, with an input voltage range that may include 9-36VDC.
Weight: 2KG or 1.2kg, depending on the source.
Dimensions: 132mm x 105mm x 52mm (outer dimensions).
Firmware Version: V2.0.0.
Program Capacity: 256kbyte.
I/O Points: PN/DP.
System Capabilities: Various, including system functions, environment, and operating system.
Function:
S20360-VTS is a PROFIBUS Redundancy Link Module for cable redundancy.
It enables the conversion between single bus and redundant dual buses.
It supports 10 common rates of the Profibus DP bus and allows rate selection or rate adaptation via dip switches.
Characteristics:
Industrial-Grade Design: Suitable for a wide range of field environments.
IP30 Protection: Ensures dust and water resistance.
Wave Aluminum Housing: Reinforces durability.
35mm DIN Rail Mounting: Allows easy installation.
DC Wide Power Input: Supports various input voltage ranges.
Relay Alarm Output: Provides additional safety and monitoring.
Dual Power Redundancy and Isolation Protection: Ensures reliability and safety.
Applications:
S20360-VTS is applicable in automation control systems where Profibus DP communication is utilized.
It can be placed directly behind a Profibus DP master station to convert a single cable bus to a redundant bus, or at a slave station to convert a redundant bus to a non-redundant cable.
It is suitable for various industries, including mining, aviation, petroleum, automotive, natural gas, and more.
