Description
argument
Power input: Supports a wide range of dual redundant power inputs (12 to 48V DC). The typical working voltage is 12V/24V/48V.
Power consumption: Full load power consumption is less than 3W (5-port 100 Gigabit switch) or less than 11W (10-port Gigabit switch).
Communication interface:
5-port Standard 100 Mbit/s: Supports 1 to 5 10/100BaseT(X) RJ45 ports and 0 to 2 100BaseFX optical ports.
10-port Gigabit network management: Supports 2 to 8 10/100/1000BASE-T(X) RJ45 electrical ports and 0 to 8 1000BASE SFP ports.
specification
Protection level:
5 port 100 megabit standard type: IP30 protection grade housing.
10-port Gigabit network management model: IP40 protective housing.
EMC design: Industrial grade 4 or industrial EMC design.
Mounting mode: Available in two mounting modes: 35mm rail or wall-mounted.
Size and weight
5 port 100 megabit standard type:
Size (length, width and height) : 116mm89mm53mm.
Net weight: 600 grams.
10-port Gigabit network management type:
Dimension (length, width and height) : 150.5mm51.5mm125.5mm.
Net weight: 900 grams.
trait
Adaptive technology: Supports Auto-Negotiation and can automatically negotiate working rate and duplex mode.
Photoelectric mixing: photoelectric mixing and flexible service interface combination can be performed.
Management function: The 10-port Gigabit NMS supports various management modes, such as Web browser, CLI, and SNMP.
Redundancy self-healing: Supports the plug and play redundant self-healing Ethernet ring technology. The fault recovery time under full load is less than 20ms.
Environmental adaptability: The operating temperature range is wide (-40℃~85℃), which can meet the requirements of various industrial sites.
