REM610

Description

• 3. Weight and Dimensions




  • Weight: The REM610 weighs approximately 6 kg. This weight is relatively manageable for installation and maintenance work, especially when handling the device in a substation environment.
  • Dimensions: It has dimensions of about 320 mm in length, 240 mm in width, and 180 mm in height. These dimensions are designed to fit into standard substation control panels and cabinets, allowing for easy integration into existing power system infrastructures.

  4. Features




  • Comprehensive Protection Functions: The REM610 offers a wide range of protection functions, including over – current protection, over – voltage protection, under – voltage protection, differential protection, and earth – fault protection. These functions can effectively detect and respond to various electrical faults in the power system.
  • Advanced Communication Capabilities: It supports multiple communication protocols, such as IEC 61850, Modbus, and DNP3. This allows it to communicate with other devices in the power system, such as remote terminal units (RTUs), control centers, and other protection relays. It enables remote monitoring, control, and data exchange.
  • User – Friendly Configuration: The device has a user – friendly configuration interface. Operators can easily configure the protection settings, communication parameters, and other functions according to the specific requirements of the power system.
•

• 1. Real – world Case




  In a medium – sized urban power substation, the REM610 was installed as a critical protection and control device for a distribution transformer. One day, a short – circuit fault occurred in the downstream power grid due to a tree branch falling on the power line.




  The REM610 quickly detected the abnormal current and voltage changes caused by the short – circuit. It immediately analyzed the fault parameters using its built – in algorithms. Based on the analysis, it issued a trip command to the circuit breaker associated with the faulty section within milliseconds.




  This rapid action isolated the fault from the rest of the power grid, preventing the spread of the fault and minimizing the impact on other consumers. At the same time, the REM610 recorded detailed fault data, including the fault time, current magnitude, and voltage waveform. This data was later used by the power grid operators for fault analysis and to improve the reliability of the power distribution system.

  2. Applications




  • Power Substations: The REM610 is widely used in power substations of different scales, from small – scale rural substations to large – scale urban substations. It provides protection and control functions for transformers, feeders, and busbars, ensuring the safe and stable operation of the power grid.
  • Industrial Power Systems: In industrial plants, it can be used to protect and control the internal power distribution systems. It helps to prevent power outages and equipment damage caused by electrical faults, ensuring the continuous operation of industrial production.
  • Renewable Energy Power Plants: For solar and wind power plants, the REM610 can be used to protect and control the power generation and transmission equipment. It can handle the unique electrical characteristics of renewable energy sources and ensure the reliable integration of these energy sources into the power grid.
•

• 5. Stability and Reliability




  • Robust Design: The REM610 is built with a rugged housing that provides protection against dust, moisture, and electromagnetic interference. This makes it suitable for use in harsh substation environments, where these factors can affect the performance of electrical devices.
  • High – Quality Components: It uses high – quality electronic components and undergoes strict quality testing during the manufacturing process. This ensures long – term stability and reliability, reducing the risk of false alarms and device failures.
  • Redundant Power Supply: Some models of the REM610 may have a redundant power supply option. In case of a power failure, the redundant power source can ensure the continuous operation of the device, preventing the loss of protection and control functions.

  6. Parameter Specifications




  • Power Supply: It operates on a 24V DC power supply, with an allowable voltage range of 21.6V to 26.4V. This wide voltage range ensures stable operation even in the presence of small power fluctuations.
  • Input/Output Channels:
    • Analog Inputs: It has 8 analog input channels for measuring electrical quantities such as current, voltage, and power.
    • Digital Inputs/Outputs: There are 16 digital input channels for detecting the status of switches and other digital signals, and 12 digital output channels for controlling relays and other actuators.
  • Communication Speed: For IEC 61850 communication, it supports data transfer rates suitable for real – time data exchange in power systems. The communication speed for Modbus and DNP3 can also be configured according to the specific requirements of the network.
  • Protection Setting Range: The protection settings, such as over – current thresholds and time – delay settings, can be adjusted within a wide range to meet the different protection requirements of various power system applications.
