Q173CPU

Description

‌Parameters‌:

• Control Axes: The Q173CPU can control up to 32 axes (depending on the model and configuration), making it suitable for advanced multi-axis control applications12.
• Operating Cycle: Offers a fast operating cycle, down to 0.88ms for the first 8 axes, ensuring responsive and precise control12.
  ‌Specifications‌:
• Processor: Equipped with a 64-bit RISC processor, enhancing processing power and performance13.
• Programming Language: Supports Motion SFC programming language, which provides improved visibility and ease of debugging13.
• Interpolation: Capable of performing linear, circular, and helical interpolation, allowing for complex motion profiles2.
  ‌Dimensions & Weight‌:
• Dimensions: Measures approximately 98mm (H) x 27.4mm (W) x 119.3mm (D), providing a compact design suitable for space-constrained environments12.
• Weight: Weighs approximately 0.33kg, making it lightweight and easy to handle
  ‌Series‌:
• Belongs to the Q series of Mitsubishi Electric motion controllers, a range of high-performance products designed for advanced automation tasks
•
  ‌Features‌:
• High-Speed Communication: Supports high-speed serial communication, enabling simple setup of servo motor synchronization or absolute systems13.
• SSCNET Connectivity: Can connect to servo amplifiers via the SSCNET (Servo System Controller Network), allowing for high-speed, high-precision positioning13.
• Enhanced Functionality: Offers various advanced features such as phase delay compensation, external signal input from servo amplifiers, and indirect zero point parameter setting5.
  ‌Role‌:
• The Q173CPU plays a crucial role in automation systems, enabling precise and responsive control of multiple axes.
• It is ideal for applications requiring high-performance motion control, such as machinery, robotics, and manufacturing processes.
