Description
Parameters and specifications
Processor: Equipped with 2.3GHz quad-core Intel Core i7-3610QE processor, single-core Turbo Boost mode up to 3.3GHz.
Memory: 4 GB (1 x 4 GB DIMMs) dual-channel 1,600 MHz DDR3 RAM is standard, expandable up to 16 GB.
System bandwidth: The maximum controller bandwidth is 8 GB per second.
Slot bandwidth: 2 GB/s.
Operating system: The Windows operating system and driver have been installed, and the recovery function based on hard disks is supported.
Size and weight
Dimensions: 115mm x 48mm x 150mm.
Weight: About 1.2kg.
trait
High bandwidth: With up to 8 GB/s of system bandwidth, it is suitable for applications dealing with large amounts of data and high bandwidth communications.
Rich interface: Integrated two 10/100/1000BASE-TX (Gigabit) Ethernet ports, two high-speed USB ports, four high-speed USB ports, as well as an integrated hard disk, serial ports, and other I/O.
High-performance processor: Equipped with a quad-core Intel Core i7 processor, providing powerful processing power.
Real-time operating system support: It can run real-time operating system to meet the application needs of high real-time requirements.
Easy maintenance and upgrade: Hard disk and memory upgrade services are provided, and users can quickly access in-ROM diagnostics of hard disk and memory.
Software Compatibility: Compatible with National Instruments’ software platforms such as LabVIEW, Measurement Studio, etc., providing a wealth of tools and development environments.
