Description
Operating system support:
Support Windows 7, Vista, XP, 2000 and other operating systems
Size and weight
Size: 13.4 x 5.0 inches (based on search results [4])
Weight: approximately 2kg (according to search results [5])
series
The PXIe-6368 belongs to the PXI series of NI data acquisition devices. PCI extensions for Instrumentation (PXI) is a rugged, PC-based measurement and automation system platform designed for industrial automation, test measurement, data acquisition, and more.
trait
High processing power: High performance data acquisition and processing with PCI Express bus and NI-STC3 timing and synchronization technology
Multi-core optimization: Drivers and application software are optimized to take full advantage of the performance of multi-core processors
Extensive software compatibility: Compatible with LabVIEW, LabWindows/CVI, Measurement Studio and many other software
Easy configuration and use: The included NI-DAQmx driver and configuration utility simplify the configuration and measurement process
Parameters and specifications
Analog Input (AI) :
16 synchronous analog inputs
16-bit resolution
Up to 2 MS/s sampling rate per channel
Total throughput of 32 MS/s
Analog Output (AO) :
4 analog outputs
16-bit resolution
Up to 3.33 MS/s update rate
Output range ±10 V
Digital I/O:
48 digital I/O lines, 32 of which are 10 MHz hardware timing lines
Counter/Timer:
4 32-bit counter/timer, support PWM, encoder, frequency, event counting and other functions
Trigger and sync:
Analog and digital triggers and advanced timing using NI-STC3 technology
