PXI-7852R

Description

Step 6: Features
High channel count and high sampling rate: Provides 8 analog input and 8 analog output channels, supporting high sampling and update rates.
Programmable FPGA chip: Equipped with Virtex-5 LX50 FPGA, it can be programmed by NI LabVIEW FPGA module to achieve flexible I/O operation and on-board processing.
Precise signal processing: Dedicated analog-to-digital converters (ADCs) and digital-to-analog converters (Dacs) per channel for independent timing and triggering.
High reliability and synchronization: Support PXI synchronous clock and environmental reference clock to ensure signal synchronization and timing.
Wide range of configuration options: Digital lines can be configured for input, output, counter/timer, pulse width modulation (PWM) and many other modes.

1. Parameters
Number of analog input channels: 8
Number of analog output channels: 8
Number of I/O channels: 96 (some sources mention 24, but most sources say 96)
Analog input sampling rate:
Up to 750 kHz (independent sampling rate)
Other sources mention a maximum of 500 kS/s
Analog output update rate: up to 1 MHz
Analog input/output resolution: 16 bits
Analog input/output voltage range: ±10 V
Digital I/O speed: up to 40 MHz (input/output/timer), with additional information mentioning up to 10 MHz
Onboard memory: 192 kB
Capacity: 1 GB
2. Specifications
FPGA model: Virtex-5 LX50 FPGA
Operating system/Target FPGA: Windows real-time system
Module width: 3U PXI module
Compatible bus: PXI hybrid bus
RoHS Compliance: Yes
