Description
Timing:
8 channels, 32-bit counter/timer module.
80 MHz maximum source frequency (up to 125 MHz with prescaler).
3 types of synchronous high-speed DMA conversion capabilities.
Digital I/O:
32 digital I/O lines (5 V TTL/CMOS).
8 dedicated digital I/O lines, and 24 shared with the counter/timer.
Digital de-bouncing filter.
Dimensions and Weight:
Dimensions: 132 mm x 105 mm x 52 mm.
Weight: The exact weight is not mentioned in the available references. It is recommended to refer to the manufacturer’s official documentation or contact NI directly for the accurate weight information.
Features:
Measurement Capabilities: Supports various counter/timer measurement tasks, including encoder positioning, event counting, period measurement, pulse width measurement, pulse generation, pulse sequence generation, and frequency measurement.
Compatibility: Compatible with TTL/CMOS-based digital devices and systems.
Programmable Input Filters: Allows for flexible input signal conditioning.
