PU516

Description

Parameters and Specifications:

Design: The PU516 features a compact and sleek design, greatly reducing desktop footprint.
Display: It incorporates a 5.7” 64K-color TFT color liquid crystal display.
Sampling Rate: It offers a real-time sampling rate of 400 MSa/s and an equivalent sampling rate of up to 25 GSa/s, ensuring effective capture of real-time transient signals.
Storage Depth: The module provides a storage depth of 1M sampling points (single channel) and 512K sampling points (dual channel).

Dimensions and Weight:

Dimensions: The exact dimensions of the PU516 module may vary slightly based on the specific model. It is advisable to refer to the official documentation for precise measurements.
Weight: Typically, the module’s weight is around 0.3kg.

Features:

Versatile Input: PU516 supports a wide range of input types and functions, making it suitable for multiple applications.
Triggering Capabilities: The module offers advanced triggering functionalities, including edge, video, pulse width, slope, alternate, pattern, and duration triggers.
Measurement and Analysis: PU516 provides 20 types of automatic measurement functions and cursor measurement, including manual mode, tracking mode, and automatic measurement mode.
Communication Interfaces: Standard communication interfaces such as USB Device, RS-232, and USB Host are supported, enabling easy integration with other devices and systems.
Calibration and Filtering: The module features automatic calibration functionality and unique digital filtering and waveform recording capabilities.
