Description
Parameters and specifications:
Type: EtherNet/IP™ to Modbus® four-port serial communication gateway.
Supported PLC types: PLC2, PLC5, SLC, CLX, CMPLX.
Supported CIP services: 0x4CCIP table read, 0x4DCIP table write.
Maximum RPI time: ms per connection (specific value not given).
Supported message types: PCCC client connection.
Connection size: 248/248.
Modbus Serial specification: Supports up to 100 commands per master port, each configurable for function code, slave address, register addressing, and word/bit count.
Series:
PROSOFT PLX31-EIP-MBS4 is part of PROSOFT Technology’s family of communication gateways.
Features:
High-speed data transfer: Enables high-speed bidirectional data transfer between EtherNet/IP™ PACs or devices and Modbus® enabled PACs or devices.
Multi-port: Four-port port for up to 400 Modbus® serial devices (external transponder required).
Easy integration: Built-in embedded EDS additional configuration files can greatly reduce debugging time and optimize performance.
Remote configuration and diagnostics: Separate DIN rail mounted gateway with an Ethernet communication port.
SD card slot: Used to store configuration files for easy fault recovery.
Wide input power and temperature range: Input power range 10 Vdc – 36 Vdc, temperature range -25°C to 70°C.
ProSoft Discovery Service: allows a PC to view a gateway and change its default IP address without being in the same subnet.
Functions:
PROSOFT PLX31-EIP-MBS4 is a protocol conversion gateway designed to enable bidirectional data transfer between EtherNet/IP™ networks and Modbus® serial devices.
Suitable for various industrial automation and control systems such as robots, SCADA systems and power monitors.
