Description
Parameters and specifications:
Control platform compatibility: Specifically compatible with the ControlLogix platform.
Power consumption: 5mA at 800 VDC and 24 mA at 3 VDC.
Supported Modbus clients and servers: Up to 30 Modbus clients and 20 Modbus servers.
Data transfer rate: 10/100 Mbps.
Network Configuration and Diagnostics: 10/100 MB Ethernet port for network configuration and diagnostics with automatic cable cross detection.
Data mapping: Supports user definable modular data memory mapping up to 10,000 16-bit registers.
Error codes and counters: Provides error codes, counters, and module status via server, client, ladder logic, and controller labels.
Temperature range: Operating temperature 0 to 60 degrees Celsius, storage temperature -25 to 70 degrees Celsius.
Size and weight:
Dimensions: Dimensions vary in different sources, but are commonly mentioned as 120mm x 80mm x 35mm.
Features:
High performance: Designed to handle high data volume and complex communication tasks to meet the real-time and reliability requirements of industrial automation systems.
Multi-client/Server functionality: Allows multiple Modbus TCP/IP clients and/or servers to be configured on a single module, simplifying communication with multiple Modbus devices.
Easy to configure and manage: With simple configuration steps, users can easily set up the module as a Modbus client or server, as well as define the required communication parameters.
Broad compatibility: Compatible with a wide range of Modbus devices, including sensors, actuators, PLCS and other automation components.
Disaster Recovery and quick replacement: Support for disaster recovery and quick replacement using industrial CompactFlash cards.
