Description
The PROSOFT MVI56E-MCMR is a communication module that offers a range of parameters, specifications, dimensions, weight, series, features, and functions. Here’s a detailed overview in English:
Parameters:
Protocols Supported: The MVI56E-MCMR supports multiple communication protocols, including MODBUS RTU/ASCII, DF1, ASCII, DH485, Modbus TCP/IP, EtherNet/IP, and AB CSP.
Power Requirements: It operates on a power supply of 5V DC.
Operating Temperature: The operating temperature range is from 0°C to 60°C.
Specifications:
Compatibility: The MVI56E-MCMR is compatible with Allen-Bradley ControlLogix processors.
Port Configuration: It comes with a dual RS232 serial application port that supports RS232/RS485 and RS422 electrical standards. Additionally, it has an RJ45 Ethernet port for debugging and configuration, supporting 10/100 base-T transmission speed.
Data Block Reduction: The MVI56E-MCMR requires less backplane/network bandwidth due to reduced data blocks, supporting simpler scheduling and transmission through control networks.
Dimensions and Weight:
Dimensions: The dimensions of the MVI56E-MCMR are 4.2 inches x 7.1 inches x 1.8 inches (107 mm x 180 mm x 46 mm).
Weight: The weight of the MVI56E-MCMR is approximately 0.5 pounds (0.23 kg).
Series:
The MVI56E-MCMR belongs to the PROSOFT MVI56 series of communication modules, which are designed for use in various automation systems.
Features:
Enhanced Modbus Communication: The MVI56E-MCMR serves as a Modbus master/slave communication module, enabling easy interfacing with devices using the Modbus RTU/ASCII serial communication protocol.
Backward Compatibility: The MVI56E-MCMR is backward compatible with previous MVI56 modules, allowing for direct replacement without changing the existing controller program.
Flexible Configuration: The module can be configured using ProSoft Configuration Builder (PCB) and Product Discovery Service (PDS), providing flexibility in setting up and managing communication parameters.
Status Monitoring: It features a 4-character scrolling alphanumeric LED display that provides simple status and diagnostic information.
Applications:
The PROSOFT MVI56E-MCMR is widely used in automation control systems, particularly in industries such as power, oil and gas, chemical, steel, water conservancy, and transportation. It enables communication and integration between devices that use various communication protocols, such as Modbus RTU/ASCII, DF1, ASCII, DH485, Modbus TCP/IP, EtherNet/IP, and AB CSP.
It’s important to note that specifications, features, and applications may vary depending on the specific configuration and use case. It is recommended to refer to the official PROSOFT documentation or contact their technical support team for the most accurate and up-to-date information.
