Description
PR6423 Sensor:
*Parameters & Specifications:
- Measures mechanical vibrations in the frequency range of 10 Hz to 1000 Hz12.
- Provides voltage signals proportional to vibration velocity12.
- Can measure amplitudes up to 2mm to 3mm peak-to-peak12.
*Dimensions & Weight:
- Various thread sizes are available, ranging from 25mm to 115mm, depending on the model3.
- Cable lengths can vary, with options like 4m, 5m, 6m, 8m, and 10m3.
- Exact dimensions and weight may vary by model; consult the manufacturer’s datasheet for specific details.
*Series:
- Part of the EPRO vibration sensor series3.
*Features:
- High sensitivity and durability, suitable for industrial applications12.
- Waterproof protection rating of IP55 or IP6512.
- Can withstand high temperatures up to 200°C12.
- Available with explosion-proof certification
*Functions:
- Monitors mechanical vibrations in rotating equipment like turbines, fans, compressors, gearboxes, and more12.
- Helps detect faults such as unbalance, misalignment, bearing wear, and crack detection4.
PR6424 Sensor:
*Parameters & Specifications:
- Used to measure static and dynamic distances between the probe and a ferromagnetic target4.
- Provides voltage signals proportional to the displacement4.
- Frequency response up to 10 kHz4.
*Dimensions & Weight:
- Various probe diameters are available, ranging from 8mm to 40mm4.
- Exact dimensions and weight may vary by model; consult the manufacturer’s datasheet for specific details.
*Series:
- Part of the EPRO displacement sensor series4.
*Features:
- Non-contact measurement capability4.
- High linearity and low error rates4.
- Operates in temperatures ranging from -30°C to 120°C for the probe and cable4.
*Functions:
- Monitors displacements, vibrations, and other parameters in rotating machinery4.
- Essential for online monitoring of rotating machinery health, including displacement, vibration, and eccentricity
