PM802F

Description

Parameters and specifications:

The PM802F has two specifications of voltage and current parameters. The first specification is that the voltage range is 100 to 240V AC, the current range is 0 to 10A, the frequency is 50/60Hz, and the power factor is 0.5 to 1.0. The second specification is the input voltage range of 12~48VDC, the output voltage of 5VDC, and the maximum output current of 10A.
Efficiency is greater than 90%.
Uses a 32-bit RISC processor.
Programming methods include instructions and ladder diagram, processing speed of 0.5us, with power outage hold function, user program capacity of 8000 steps.
With a variety of timers, such as 100mS timer, 10mS timer and 1mS timer, the specifications are 0.1~3276.7 seconds, 0.01~327.67 seconds and 0.001~32.767 seconds.
The counter specifications include 16-bit counters and 32-bit counters with set values ranging from K0 to 32,767 and K0 to 2,147,483,647, respectively.

Size and weight:

Dimensions: 170mm x 105mm x 32mm.
Weight: About 120g.
Series:
The PM802F is part of ABB’s automation and control systems portfolio.
Features:
The PM802F is a compact, versatile power meter that provides measurement and comprehensive power analysis for a variety of electrical systems.
The controller has fast and reliable processing speed, adopts high speed processor and advanced algorithm.
It has a large capacity of memory and supports a variety of communication protocols, such as Ethernet, Profibus, CAN, etc.
Easy to program and debug, support a variety of programming languages.
