Description
User program capacity: 8000 steps (24K steps for confidential download).
I/O points: Input 18 points/output 14 points.
Internal coil count: 8000 points.
Timer points: 620 points, including 100mS, 10mS and 1mS timer.
Counter count: 635 points, including 16 and 32 bit counters.
Data register: 5000 words.
FlashROM register: 64 words.
Extended internal register: 36,864 words.
dimension
Size: Different data give different size information. One saying is 170mm x 105mm x 32mm, another is 132mm x 105mm x 52mm, which may be a size difference between different models or configurations.
weight
Weight: about 120g, but there are also claims that the weight is 2KG, which may also be related to different models or configurations.
argument
Input voltage range: Depending on the search results, the input voltage range of the PM802F will vary. One is 12-48VDC, the other is DC9-36V wide redundant dual power supply, typical DC24V.
Output voltage: 5VDC.
Output current: Maximum 10A, but there are also claims that the current range can reach 100-400A, which may be related to different configurations or application scenarios.
Efficiency: greater than 90%.
Operating temperature: -20°C to +50°C, with a wider temperature range also mentioned.
specification
Program execution mode: cyclic scanning mode, timed scanning mode.
Programming mode: instruction and ladder diagram.
Processing speed: 0.5us.
