PM783F 3BDH000364R0001

Description

Product parameters:

Module type :PM783F
Code :3BDH000364R0001
Manufacturer :ABB
Module type :CPU
Processor: Built-in
Ethernet interface :100mbit /s
Serial interface :2
Memory :10mb, of which 2mb is battery protection
Dimensions (L x W x H):54 mm x 76 mm x 67.5 mm
Weight :0.15 kg

Specifications:

Cycle: Adjustable, cycle rate adjustable, and a PLC-type cycle that runs at the maximum possible speed
Diagnostics: There is a small front display that displays status and diagnostic information
Protection: A controller lock (key lock) prevents applications and firmware from loading, thereby increasing security. The lock/unlock status is displayed on the monitor
I/O module connection: Up to 8 I/O modules can be connected, or I/O modules can be connected using MODBUS ASCII/RTU, IEC 60870-5-101 or PROFIBUS
Data exchange :I/O scans can occur as often as 2 milliseconds. Each channel is equipped with short circuit detection and deactivation
Compatibility :PM 783F is a PLC-based DCS that is particularly suitable for systems with multiple to 300 I/O signals. It does not require you to download the operating system when installing the software
Power supply :24VDC
Software version :2013 SP1 RU04, 2016 SP1 RU03 or higher
