Description
Basic specifications and functions
Product type : programmable logic controller module.
main role : designed for industrial automation applications, to meet the complex control needs, improve production efficiency and system reliability.
weight
Net weight : 800g.
Details
communication rate : adaptive, specific rates can be set through the dip switch, such as 9.6Kbps, 19.2Kbps, etc., up to 1.5Mbps.
optical fiber interface : Support multi-mode 850nm, 1310nm and single-mode 1310nm, 1550nm, transmission distance of multi-mode 2Km, single-mode 20Km.
electrical and data interface : one or two 5-PIN terminal interfaces that support the CAN BUS/DeviceNet/CANOpen bus standard.
power supply : dual power supply with redundant input, DC(9-36)V, typical DC24V, power consumption less than 4W.
protection : 4000V lightning protection, 1.5A overcurrent protection, 600W surge protection.
Dimensions and mechanical properties
Overall dimension : 132mm105mm52mm (high depth and width).
housing : IP30 protection grade, corrugated aluminum reinforced housing.
installation method : 35mm guide rail installation.
Working environment
Operating temperature : -10-70℃ (wide temperature -40~+85℃ optional).
relative humidity : ≤90% (non-condensing).
