PM511

Description

‌Parameters & Specifications‌:

–‌Model‌: PM511
–‌Bus Interface‌: PC104-Plus1
–‌A/D Conversion Channels‌: 8 single-ended or differential1
–‌D/A Conversion Channels‌: 4 independent1
–‌Switchable I/O Channels‌: 24 programmable TTL-level1
–‌Counter Channels‌: 31
–‌Input Signal Range‌: 0-10V, -5V to +5V (A/D)1
–‌Output Signal Range‌: 0-5V, -5V to +5V (D/A)1
–‌Input Accuracy‌: 12-bit resolution1
–‌Output Accuracy‌: 12-bit resolution1
–‌Sampling Frequency‌: Up to 100KHz (A/D)1
–‌Maximum Count Frequency‌: 10MHz (Counter)1
‌Dimensions & Weight‌:

–‌Dimensions‌: Approximately 91mm x 96mm

‌Series‌:

• Part of a series of industrial data acquisition and control boards. The exact series name may vary depending on the manufacturer.
  ‌Features‌:

–‌High-Resolution Data Acquisition‌: Provides 12-bit resolution for both analog input and output, ensuring precise measurements and control1.
–‌Versatile I/O‌: Offers 24 programmable switchable I/O channels and 3 counter channels, making it suitable for a wide range of applications1.
–‌Compact Design‌: The PC104-Plus bus interface allows for compact installation in embedded systems and industrial PCs1.
–‌Ease of Use‌: Supports software-triggered and timer-triggered A/D conversions, as well as programmable D/A output1.
‌Functions‌:

–‌Data Acquisition‌: Collects analog and digital signals from sensors and devices, converting them into digital data for processing1.
–‌Signal Generation‌: Generates analog output signals for control applications, such as driving actuators or simulating sensor inputs1.
–‌Counting & Timing‌: Counts pulses or measures time intervals using the built-in counter channels1.
–‌Industrial Automation & Control‌: Integrates seamlessly into industrial automation systems, facilitating efficient and precise control of machines and processes
