Description
argument
Manufacturer: ProSoft Technology
Product Number: PLX31-MBTCP-MBS4
Product Type: Modbus TCP/IP to Modbus Serial 4-port gateway
Power supply: Nominal 24 VDC, allowing 10 to 36 VDC, positive, negative, GND terminals
Current load: 24 VDC nominal @ 300 mA, 10 to 36 VDC @ 610 mA maximum
Operating temperature: -25 ° C to 70 ° C (-13 ° F to 158 ° F)
Storage temperature: -40 ° C to 80 ° C (-40 ° F to 176 ° F)
Vibration: IEC 60068-2-27; 15g @ 11ms, three-axis (run), IEC 60068-2-27; 30g @ 18ms, 3 axes (not working)
Relative humidity: 5% to 95% RH, non-condensing
Output frequency: 350kHz (However, please note that this information may be related to other models or scenarios, please refer to the product manual for details)
specification
Number of serial ports: 4
Serial isolation: 2500 Vrms, using RF (radio frequency) modulated signals as isolation media
Ethernet port: 10/100Mbit half-duplex RJ45 connector, electrical isolation 1500 Vrms
Ethernet broadcast storm recovery: less than or equal to 5000 [ARP] frames per second, duration less than or equal to 5 minutes
Size and weight
Dimensions: Approx. (H x W x D) 13.67 x 5.05 x 11.13 cm
Shipping weight: 2.5 kg
series
PLX31-MBTCP-MBS4 is a model in the Modbus gateway family produced by ProSoft Technology.
trait
High-speed bidirectional data transfer: High-speed bidirectional data transfer between Modbus TCP/IP PAC and Modbus serial devices can be achieved
Multi-device connectivity: Up to 400 Modbus serial devices can be connected through four serial ports (external transponder required)
Multi-client and Server support: Up to 20 simultaneous client and server connections are supported
Flexible configuration: Built-in SD card slot (SD card is optional), convenient configuration file storage and fault recovery
Remote administration: The ProSoft Discovery Service utility allows you to view the gateway and change the default IP address without being on the same subnet
effect
The PLX31-MBTCP-MBS4 gateway plays a key role in industrial automation by connecting Modbus TCP/IP networks with traditional Modbus serial devices for seamless data transmission and exchange. This is especially important for industrial applications that need to integrate old and new equipment and extend system capabilities. With this gateway, users can more flexibly build and scale automation systems, increasing productivity and reliability.
