Description
argument
Model: PFTL 101B 2.0KN
Rated load: 2.0KN
Input voltage: 24vdc
Output signal: 4 ~ 20ma
Accuracy: ±0.25% FSO
Operating temperature: -40℃~ 85℃
Protection level: IP67
specification
Rated capacity: 2.0KN
Sensitivity: 2.0mV /V±0.25%
Zero balance: ± 0.1mV /V
Nonlinearity: ±0.05% FSO
Hysteresis: ±0.05% FSO
Repeatability: ±0.05% FSO
** Creep (30 minutes)** : ±0.05% FSO
Input resistance: 400Ω ± 20Ω
Output resistance: 350Ω ± 3Ω
Insulation resistance: ≥5000 MΩ (50vdc)
Excitation voltage: 10vdc
Maximum excitation voltage: 15vdc
Cable length: 3m
Size and weight
Size: Specific size information can vary by product design and manufacturer and can usually be found in the product manual or on the official website.
Weight: Specific weight information can also vary by product design and manufacturer and can usually be found in the product manual or on the official website.
series
The ABB PFTL 101B 2.0KN is part of ABB’s PFTL family of load cells. The range may include other models and specifications of sensors to meet different application needs.
trait
High accuracy: ±0.25% accuracy, providing accurate weighing and measuring functions.
Wide operating temperature range: It can work normally in the temperature range of -40℃ to 85℃.
High protection rating: The IP67 protection rating means that the sensor has good water and dust resistance and is suitable for harsh industrial environments.
Easy to configure and debug: It is usually equipped with simple configuration and debugging tools for users to set up and calibrate.
