Description
argument
Measuring range: 2.0 kN (kN)
Electrical interface: analog interface, analog current output interface is 4mA~20mA
Operating voltage: 24VDC (19… 30VDC)
Current power consumption: ≤ 100 mA
Insulation impedance: ≥ 10MΩ (500 VDC)
Temperature coefficient: <30ppm/K
Operating temperature range: -40… + 85 ℃
Storage temperature range: -40… + 105 ℃
Working humidity range: 0… 95% (no condensation)
specification
Type: Pressure/tension sensor
Measurement technique: NOVOSTRICTIVE non-contact magnetostrictive measurement principle
Resolution: Up to 0.001 mm
Accuracy: Absolute linearity ≤± 0.02% F.S.
Repeatability: ≤ 0.03% F.S.
Magnetic induction lag: ≤ 0.01% F.S.
trait
High precision: With high precision and excellent linear performance
Durability: No mechanical wear, unlimited mechanical life, excellent resistance to shock or vibration
Flexibility: Optional live isolation, optional output cable or plug, available in a variety of configuration options
Protection class: IP67/IP68, able to withstand exposure to moisture and pollutants
Corrosion resistance: Available in acid-resistant version, made of AISI 316L stainless steel, suitable for use in harsh conditions
