Description
argument
Working voltage: DC24V (18-36V)
Power: 7.5W
Output frequency: 30Hz
Number of tension units: 2
Excitation signal current: 0.5Ams, 330Hz
Power consumption: +5V@250mA, +3.3V@10mA
specification
Structure: Modular
Installation: Installation in the control room
LD instruction processor: hard PLC
Function module: including two load cell input, voltage and current output A+B, with adjustable filtering function
Display: A, B, A+B, A-B can be displayed on the display
Size and weight
Dimensions: Height x width x Depth = 180 x 120 x 100 (unit: mm)
Weight: 1.9 kg (shipping weight is 3 kg)
trait
Flexibility: Distributed tension control system with scalability
High precision control: used to monitor and control the tension of continuous materials (such as paper, film, cable) to ensure the stability and quality of the production line
Reliability and stability: with good maintainability, remote monitoring and management capabilities
Communication capability: Support a variety of communication protocols and external PLC/DCS integration
Protection level: There are IP20 and IP65 protection levels, corresponding to non-sealed type and dustproof and waterproof type respectively
Signal processing: Through amplification, correction and filtering to achieve accurate and reliable signal output
