PFEA111-65

Description

Parameters and Specifications:

Manufacturer: ABB
Model Number: PFEA111-65
Product Type: Tension Controller
Inputs: 2 weight transducer inputs, voltage and current outputs
Display: On-display A, B, A+B, and A-B, including CD user manual
Power Supply: 24 V DC, IP 65 (NEMA 4)
Fuse: IP 65 (NEMA 4) slow-acting fuse, 2 A, 250 V
Current Consumption: 0.5 A RMS, 330 Hz
Input Quantity: 2
Input Impedance: 10 kohm
Operating Temperature Range: +5 to +55 °C (32 to 131 °F)
Non-Operating Temperature Range: -40 to +70 °C (-40 to 158 °F)
Dimensions: 180 x 120 x 100 mm
Weight: 1.9 kg

Features:

Multiple Inputs: The controller accepts inputs from two weight transducers for precise tension control.
Display Options: Users can view tension data on multiple displays (A, B, A+B, A-B).
Easy Setup: The controller includes a CD user manual for convenient setup and operation.
Robust Design: The controller is designed to withstand harsh industrial environments with an IP 65 (NEMA 4) rating.
Flexible Power Supply: It accepts a 24 V DC power supply.
Adjustable Filtering: The controller features adjustable filtering for precise tension control.

Applications:

The ABB PFEA111-65 is commonly used in various industrial applications, including printing machines, coating machines, paper processing machines, textile machinery, cigarette machines, packaging machines, and metal processing equipment. It ensures stable tension and quality of continuous materials during production.
