PCI-8512

Description

Parameters and Specifications:

Channels: 4-channel data acquisition card with 12-bit resolution.
Sampling Rate: Supports sampling rates up to 40MS/s or 20M/40M, depending on the input signal frequency.
Input Range: The analog input range can be programmed to ±1V or ±5V.
Memory: Equipped with up to 2GB of on-board memory, eliminating the need for PCI bus bandwidth limitations.

Dimensions and Weight:

The specific dimensions and weight of the NI PCI-8512 card are not provided in the given references. However, they are typically designed to fit standard PCI slots and are compact in size for easy installation within a computer chassis.

Features:

High Resolution: With 12-bit analog-to-digital converter (ADC), it provides high-resolution data acquisition.
High Sampling Rate: Supports high sampling rates, making it suitable for high-frequency signal acquisitions.
Programmable Input Range: The ability to program the input voltage range adds flexibility to the card’s operation.
Large On-Board Memory: The availability of on-board memory allows for longer data acquisition sessions without relying on the PCI bus bandwidth.
Automatic Calibration: Features automatic calibration for accurate measurements.
