Description
Parameters and specifications:
Input channels: The PCI-6254 has 32 single-ended or 16 differential analog input channels with a 16-bit resolution and a maximum sampling rate of 1.25 MS/s.
Digital I/O: Provides 48 digital I/ OS.
Counter/timer: Has 2 32-bit counter/timer I/O lines at 80 MHz.
Analog input maximum operating voltage: ±11 V, this range is suitable for signal mode and common mode.
Sampling rate: The maximum sampling rate per channel is 1.25 MS/s, and the maximum average sampling rate for multiple channels is 1 MS/s.
Size and weight:
Dimensions: 3.8 x 6.1 inches.
Weight: 5.3 ounces.
Series:
PCI-6254 is one of NI’s M series data acquisition cards.
Features:
High accuracy: NI-MCal tuning technology and NI-PGIA 2 programmable amplifiers improve measurement accuracy.
High speed: Ensures 16-bit resolution accuracy even at maximum speeds.
Rich software support: including NI LabVIEW SignalExpress LE communication data resolution software and Ni-DAQMX driver software.
Flexibility and scalability: Users can configure the channel according to their needs, including input range, filter Settings, and more, and at the same time, as a PCI interface card, it can be used with other PCI devices to build complex test systems.
Built-in NIST traceable standardization system and more than 70 signal conditioning options.
Functions:
PCI-6254 is suitable for scenarios that require high-precision data acquisition and processing, such as laboratory testing, industrial automation, and control systems. Its high-speed and high-resolution characteristics allow it to quickly capture dynamic signals and ensure the accuracy and precision of measurement data.
