PCI-6115

Description

argument
Input voltage: 24VDC, but supports a wide range of input voltages, including 85-264V AC, 47-63 Hz or 110-370V DC
Output voltage: 24V DC
Output power: 450 W
Maximum output current: not given directly, but usually related to output power and voltage
Operating temperature range: -40°C to +70°C
specification
Analog input: 4 high-speed analog inputs, each channel 10 MS/s
Analog output: 2-channel 12-bit analog output, 4 MS/s single-channel update rate, 2.5 MS/s dual-channel update rate
Digital I/O: Eight digital I/O lines
Counter/timer: 2 24-bit counters
On-board memory: High capacity on-board memory (32 or 64 MS)
Input range: Extended up to ±42 V
dimension
Physical dimensions: 166mm x 112mm x 36mm
weight
Product weight: 1.3 kg
trait
High sampling rate: The sampling rate is 10 MS/s per channel
Wide input range: 8 input ranges from ± 0.2V to ± 42V
Onboard anti-aliasing filter: software optional
High capacity on-board memory: Ensures reliable data read and write ability
Dedicated analog-to-digital converters (ADCs) per channel: Provide the most powerful device processing power and higher multi-channel accuracy
Ni-daqmx driver software and NI LabVIEW SignalExpress interactive data logging software: support users for data acquisition and analysis
