Description
Parameters and Specifications:
Voltage: 24V DC (some sources mention 120VDC, but 24V DC is more commonly listed)
Current: Ranges from 100-400A
Communication Interface: Etherner (Ethernet)
Dimensions:
Size: Approximately 23cm in length (some sources mention dimensions like 10*21, but 23cm is more specific and likely refers to length)
Height: 53mm
Weight:
Weight: Varies between 0.2kg and 2KG, with 2KG being more likely for the complete module including packaging or accessories23. Another source mentions 2.4lb (approximately 1.09KG), which is close to 2KG
Series:
Belongs to a series of communication input/output modules used in industrial automation systems.
Features:
Protection and Monitoring: Provides monitoring and protection functions for power systems to safeguard generator operation
Communication Capability: Allows communication with other systems for remote monitoring and control5.
Voltage Regulation: Ensures the generator output voltage meets set standards
Excitation Control: Maintains power system stability by controlling generator excitation current
IP45 Protection: Offers dust and water resistance suitable for harsh industrial environments
Modular Design: Facilitates easy integration and expansion within industrial automation systems.
Role and Application:
The PCD231B101 3BHE025541R0101 serves as a critical component in industrial automation systems, particularly in power generation and heavy industries such as chemical plants.
It is used for monitoring, controlling, and protecting electrical systems, ensuring stable and efficient operation of generators and other equipment.
Its features make it suitable for applications requiring precise control and monitoring of electrical parameters in harsh industrial environments
