NI SCXI-1104C

Description

The NI SCXI-1104C is a high-performance data acquisition module produced by National Instruments (NI) that belongs to the SCXI (Signal Conditioning eXtensions for Instrumentation) series. It offers a range of features and specifications designed for various precision data acquisition applications. Here is a detailed overview of its parameters, specifications, dimensions, weight, series, features, and applications in English:

Parameters and Specifications:

• Differential Input Channels: The module provides 16 differential input channels¹, or 32 differential channels depending on the specific configuration², which are suitable for higher voltage signal conditioning.
• Maximum Sampling Rate: The maximum sampling rate is 100 kS/s¹.
• Resolution: It offers a resolution of 24 bits¹, ensuring high-precision data acquisition.
• Input Voltage Range: The input voltage range is ±10 V¹.
• Input Impedance: The input impedance is specified as 1 MΩ || 5 pF¹.

Dimensions and Weight:

• Dimensions: The dimensions of the NI SCXI-1104C module are 3.3 x 22.9 x 14.0 cm¹³.
• Weight: The weight is approximately 0.36 kg¹³.

Series:

• The NI SCXI-1104C is part of the SCXI series, a range of modules designed for signal conditioning and data acquisition in instrumentation applications⁴⁵.

Features:

• High Performance ADC: It incorporates a high-performance analog-to-digital converter (ADC) for high-resolution and high-precision data acquisition⁴.
• Multi-channel Acquisition: Supports simultaneous acquisition of multiple channels, enabling the connection of multiple sensors or signal sources⁴.
• Flexibility and Programmability: The module is highly flexible and can be programmed using languages like LabVIEW to meet specific application needs⁶.
• Signal Conditioning and Amplification: It may be used for signal conditioning and amplification to ensure that the acquired signals have the appropriate amplitude and accuracy⁵.

Applications:

• Laboratory Measurement and Testing: The NI SCXI-1104C can be used in laboratory environments for measuring and testing various signals, including voltage, current, temperature, and more⁵.
• Automation Testing Systems: It integrates well into automation testing systems, enabling the collection and analysis of test data⁵.
• Education and Academic Research: The module’s ease of use and flexibility make it suitable for use in education and academic research settings⁵.
• Vibration and Noise Analysis: It can be used to collect data from vibration sensors or microphones for vibration and acoustic analysis⁵.
• Temperature and Environmental Monitoring: The NI SCXI-1104C may also be employed for monitoring environmental parameters such as temperature, humidity, and gas concentration⁵.
