NI SCXI-1104C

Description

The NI SCXI-1104C is a high-performance data acquisition module from National Instruments (NI). It is part of the SCXI (Signal Conditioning eXtensions for Instrumentation) series, designed for precise and reliable data acquisition in various applications¹²³⁴. Here are the key parameters, specifications, dimensions, weight, series, features, and applications of the NI SCXI-1104C module in English:

Parameters and Specifications:

• Channels: The module typically supports multiple analog input channels, enabling simultaneous acquisition of multiple signals¹²³⁴.
• Sampling Rate: It has a maximum sampling rate of 100 kS/s, which determines the number of data points collected per second¹.
• Resolution: With a resolution of 24 bits, the module provides high-precision data acquisition¹.
• Input Voltage Range: ±10 V, suitable for a wide range of sensor signals¹.
• Input Impedance: 1 MΩ || 5 pF, ensuring accurate signal transmission¹.

Dimensions and Weight:

• Dimensions: 3.3 x 22.9 x 14.0 cm, making it suitable for various environments and applications¹⁵.
• Weight: 0.36 kg, ensuring easy handling and installation¹⁵.

Series:

• The NI SCXI-1104C belongs to the SCXI series of signal conditioning and data acquisition modules²⁵.

Features:

• High Performance: Equipped with a high-performance ADC (analog-to-digital converter), it provides high-resolution and high-precision data acquisition².
• Multi-Channel: Supports simultaneous acquisition of multiple channels, enabling connection to multiple sensors or signal sources².
• Flexibility and Expandability: The module’s modular design allows for easy integration and expansion to meet different application needs²³⁴.
• Programmability: Can be configured and controlled using programming languages like LabVIEW, offering flexibility in customization and control⁴.
• Versatility: Suitable for various measurement tasks, including voltage, current, resistance, and other signal types⁴.

Applications:

• The NI SCXI-1104C is widely used in scientific research, industrial automation, test and measurement, and other fields that require high-precision data acquisition¹³⁴⁶. It is particularly suitable for real-time acquisition, monitoring, and analysis of analog signals, such as temperature, pressure, flow rate, vibration, and other physical quantities⁴.
