Description
The NI PXIE-8523 is a high-performance hardware module specifically designed for automotive Ethernet applications. It is a 4-port, 100/1000BASE-T1 PXI automotive Ethernet interface module that integrates seamlessly with NI-XNET drivers for application development.
Parameters and Specifications:
Ethernet Bandwidth: The PXIE-8523 offers an Ethernet bandwidth of 1 Gbits/s, enabling high-speed data transmission.
Port Number: It provides four independent ports or a maximum of two network terminal access points (TAPs).
Compatibility: The module is compatible with the NI-XNET driver, which supports the development of applications for automotive Ethernet and the validation of automotive electronic control units (ECUs).
Features:
Board-Mounted Hardware Timestamp: The PXIE-8523 incorporates a board-mounted hardware timestamp, enabling it to operate as up to four independent 802.1AS master or slave stations, synchronizing with external networks and the rest of the PXI system.
LED Indicator: The front panel features LEDs for monitoring network connections and activities, providing real-time feedback on the module’s status.
Compact Design: Its compact size and reasonable weight facilitate integration into existing test systems.
Size and Weight:
The PXIE-8523 is designed for compactness, which makes it easy to integrate into various testing environments. However, specific dimensions and weight may vary, and it is recommended to refer to the official documentation or contact the manufacturer for accurate measurements.
Series:
The NI PXIE-8523 belongs to the PXI Express (PXIe) series of hardware modules offered by National Instruments (NI).
Role/Application:
The NI PXIE-8523 is highly suitable for development applications that require testing automotive Ethernet and validating automotive ECUs. It provides a robust and reliable platform for real-time data acquisition, control, and analysis in automotive networks.
