Description
NI PXIe-6739 Parameters, Specifications, Dimensions, Weight, Series, Features, and Functions in English
Parameters and Specifications:
Model Number: PXIe-6739.
Brand: National Instruments (NI).
Bus Connector: PXI Express.
Analog Output Channels: 64.
Maximum Update Rate: 1 MS/s (mega-samples per second).
Voltage Range: -10 V to 10 V.
Resolution: 16 bits.
Current Range: Specified by the manufacturer.
Part Number: 783801-01.
Dimensions and Weight:
Dimensions: 10.6CM × 9.3CM × 2.3CM (Length × Width × Height).
Weight: Approximate weight or weight range is not specifically mentioned. Actual weight may vary based on packaging and accessories.
Series:
The NI PXIe-6739 belongs to the NI PXI series of modular instruments, specifically designed for use in PXI systems.
Features:
High-Density Analog Output: Ideal for high-density incentive-response testing and open-loop simulations.
Static and Software-Timed Voltage Output: Supports various voltage output applications.
Integrated Digital I/O Lines: Features 20 digital I/O lines, 4 counters/timers, digital triggers, and advanced timing capabilities.
Flexible Configuration: Can use up to 16 channels to achieve higher sampling rates, with each channel located in different groups.
Coupling Capability: Its digital trigger and PXIe synchronization abilities enable it to couple with other data acquisition, motion, and vision products, creating highly customized measurement solutions.
Functions/Role:
The NI PXIe-6739 PXI analog output module provides analog output signals to PXI systems.
It is suitable for control and waveform output applications, including incentive-response, power control, high-speed, deterministic control, and sensor/signal simulations.
Its advanced features make it a replacement for multiple instruments, such as independent proportional-integral-derivative (PID) controllers, low-speed arbitrary waveform generators, and function generators.
