Description
The NI PXIe-6739 is a high-performance analog output module designed for use in PXI systems. It offers exceptional capabilities for a wide range of applications, including high-density excitation-response testing and open-loop simulation.
Parameters and Specifications:
Channels: The module provides 64 analog output channels, each capable of achieving high sampling rates.
Resolution: It offers a resolution of 16 bits, ensuring precise and accurate output signals.
Update Rate: The maximum update rate is 1 MS/s, allowing for fast and responsive signal generation.
Voltage Range: The voltage range extends from -10 V to 10 V, covering a wide range of output needs.
Dimensions and Weight:
Dimensions: The module has a standard PXI form factor, typically measuring approximately 10.6CM × 9.3CM × 2.3CM.
Weight: The weight may vary depending on the specific configuration and accessories, but it is generally lightweight for easy installation and handling.
Series:
The NI PXIe-6739 belongs to the PXI Express series of modules, which are designed for use in high-performance test and measurement applications.
Features:
High Density: The module’s high channel density makes it ideal for applications that require a large number of analog outputs.
Flexible Configuration: It supports up to 16 channels for high sampling rates, with each channel located in different groups.
Digital I/O Lines: The module includes 20 digital I/O lines, enhancing its connectivity and control capabilities.
Advanced Timing: The module’s digital trigger and PXIe synchronization capabilities enable coupling with other data acquisition, motion, and vision products, allowing users to build highly customized measurement solutions.
Role/Application:
The NI PXIe-6739 analog output module is ideal for a wide range of applications that require precise and reliable analog signal generation. It is commonly used in high-density excitation-response testing, open-loop simulation, control systems, sensor/signal simulation, and other areas where accurate analog outputs are crucial.
