Description
The NI PXI-6052E is a versatile and high-performance multifunction data acquisition (DAQ) device that offers precision and reliability in a range of applications. Here are its key parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters and Specifications:
Analog Inputs: The NI PXI-6052E provides 16 single-ended inputs or 8 differential inputs, allowing for precise analog signal acquisition.
Analog Outputs: It features 2 analog outputs for generating analog signals.
Digital I/O Lines: The module offers 24 digital I/O lines for digital signal control and monitoring.
Resolution and Sampling Rate: It has a 16-bit resolution, delivering accurate measurements. Depending on the configuration, it can achieve sampling rates of up to 333 kS/s per channel.
Counters and Timers: The module is equipped with two 24-bit counters/timers for advanced timing and measurement functions.
Dimensions and Weight:
Dimensions: The NI PXI-6052E measures approximately 6.3 x 3.9 inches (160 x 99 mm).
Weight: It weighs approximately 7.2 ounces (204 grams).
Series:
The NI PXI-6052E belongs to the National Instruments’ (NI) PXI series of modular instrumentation devices.
Features:
Versatility: The module supports a wide range of analog input ranges, making it suitable for various measurement tasks.
No-Switch, No-Jumper Design: Its design eliminates the need for switches or jumpers, simplifying usage and setup.
Software Compatibility: The NI PXI-6052E is compatible with various software development environments, including LabVIEW, and can be configured and programmed using the NI-DAQ 6052 driver software.
Functions/Applications:
Data Acquisition: The NI PXI-6052E is designed for precision data acquisition, allowing for the collection and analysis of analog and digital signals from various sources.
Testing and Measurement: It finds applications in testing and measurement systems, where accurate and high-speed data acquisition is critical.
Automation and Control: The module can be used in automation and control systems, enabling precise monitoring and control of industrial processes.
Please note that specifications and features may vary slightly depending on the manufacturer’s revision or any customizations made to the module. It is always advisable to consult the official product documentation or contact the manufacturer for the most accurate and up-to-date information.
